1955 - BMW 507 Wallpapers for PC
The 507 shared the frame of the 503, shortened from 2835 mm (111.6 in) to 2479 mm (97.6 in). Overall length was 4835 mm (172.6 in), and overall height was a low 1257 mm (49.5 in). Curb weight was about 1,485 kg (2,835 lb). The body was hand-formed of aluminum, and no two models were exactly the same.
Front suspension was parallel double wishbones, with torsion bar springs and an anti-roll bar. Rear suspension had a live axle, also sprung by torsion bars, and located by a Panhard rod and a central, transverse A-arm to control acceleration and braking forces. Brakes were Alfin drum brakes of 284.5 mm (11.2 in) diameter, and power brakes were optional. Late-model 507s had front disc brakes.
The engine was the aluminum alloy BMW OHV V-8, of 3.2 L (195.8 in³) displacement, with pushrod-operated overhead valves. It had two Solex Zenith 32NDIX two-barrel carburetors. It rated 150 hp (111.9 kW) DIN, with 160 hp (119.4 kW) optional. It was mated to a four-speed manual transmission with various rear-end ratios optional. It was capable of 0-60 mph (0-96 km/h) in about 10 seconds, with a top speed of about 125 mph (200 km/h) depending on gearing.
